Installation instruction For Solar Panel Matched with PTZ Camera
Jun 29, 2021
Note:
Do not tighten the bolts during assembly.
Tithten all the bolts after assembly.
- The solar panel is laid flat, and the bracket is fixed to the solar panel with M6 * 20 bolts. Note that the "L" opening faces outward.
- Use M8 * 20 bolts and assemble as shown in the figure.
- Use M8 * 20 bolts to fix as shown in the figure.
- Select the corresponding hoop according to the diameter of the pole to fix it to the pole.
