20X/30X/36X 4K FTD IR6 High speed Ptz dome IP infrared Camera

Fengtaida
2022IR6
100 In stock
MSRP: $3,800.00 $1,399.00
revolution :
optical zoom :
Night vision :
$1,399.00

Product advantage:

  • up to 4K resolution
  • Powerful Up to 36X optical zoom
  • H.265 Encoding
  • Support PoE and wifi, Auto-tracking
  • IR distance up to 500m
  • IP67, IK10

Product Parameter.

 Network Network Interface Ethernet 10/100Base-T (RJ-45)
Network Protocol TCP/IPHTTPNTPIGMPDHCPUDPSMTPRTPRTSPARPDDNSDNSP2P
Compatibility Support Hikvision,XM,TOPSEE etc center platform management software
Interface Protocol ONVIF2.4/GB28181(Option- Customize)
Mobile monitoring Operating System Android/IOS
Camera Image Sensor 1/2.5” 5.0M 5521CMOS
Optical Zoom 10X-36X
Minimum Illumination Color: 0.1Lux@F1.5; B/W: 0.01Lux@F1.5; 0Lux(IR on)
WDR More than 80dB
S/N Ratio More than 50dB(AGC off)
Day/Night Auto(ICR) / Color / B/W
Angle of View H: 61.2° ~ 2.32°
Electronic Shutter Speed 1/2 - 1/20,000s
Noise Reduction DNR,3DNR
Defog Support
Max. Aperture F1.5~F1.9
White Balance Auto, ATW, Indoor, Outdoor, Manual
Gain Control Auto / Manual
 Video Compression H.265/H.264/MJPEG
Video Interface 1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC (S/N ratio 55dB)
Resolution Main stream:2592x1944,2592x1520,2304x1296,1920x1080,1280x960,1280×720,720×576,640×480
Sub stream:640×480,352×288,320×240,176×144
MJPEG:1920x1080,1280×720
Max Frame Rate H.265/H.264: 2592x1944@15fps2592x1520@22fps
Bitrate MainStream:10.0Mbps@VBR/Sub Stream:32Kbps@VBR
 Audio Algorithm G711,G726,PCM,AAC
Input 1 x Line-In (Mini-stereo, Single Mono)
Output 1 x Line-Out (Mini-stereo, Single Mono)
Pan/Tilt Range Pan : 360°(Endless)/ Tilt: -10~90°
Pan/Tilt Speed Preset Max.:240°/sec
Manual : 0.1° ~ 180°/sec (Zoom Proportional)
Patrol : 1.4°~240° /sec
Preset 241Presets and 14 presets for special function
Patrol Scan 3 Group Patrol
Other Functions Auto Flip, Auto Parking, Power-up Action & etc
Alarm Alarm Input 1(ON/OFF signal)
Alarm Output 1(ON/OFF signal)
Infrared IR distance 200m-500m(Max.)
Wave 850nm
 Physical  IP protection With IP67
Operating Temperature –45~70
Humidity 0%~98% (Non condensing)
Store TF Card
Power Source AC24V 3A 60Hz/50Hz; DC12V 5A ;POE
Power Consumption AC24V8W-45W    DC12V/POE8W-36W
Custom and contact us.
