Professional, heavy-duty wall mount bracket designed for stable, vibration-free installation of large PTZ dome cameras. Designed with an integrated cable chamber, this bracket protects wiring from physical cutting and elements while delivering a clean architectural aesthetic.
Key Engineering Highlights
- Anti-Vibration Engineering: Reinforced structural ribbing on the neck prevents high-speed PTZ cameras from vibrating during rapid panning or zooming.
- Integrated Wiring Hood: Feed cables through the wall directly into the bracket base, sealing out moisture and protecting wires from exposure.
- Excellent Load Margin: Safely supports up to 15 kg (33 lbs) with a 4x static load safety factor, complying with international building standards.
- Premium ADC12 Aluminum: Lightweight yet stronger than cast iron. Powder coating prevents peeling or discoloration under direct afternoon sunlight.
Engineering Specifications
| Parameter | Value |
|---|---|
| Material | Die-cast Aluminum (ADC12) |
| Load Capacity | 15 kg (33 lbs) |
| Mounting Thread | Standard G1.5 female threaded adapter |
| Ingress Seal | Internal rubber gasket ring included |
| Dimensions | 97 mm (W) x 182 mm (H) x 305 mm (D) |
Typical Field Scenarios
The standard choice for mounting high-speed PTZ speed domes onto building brick walls, concrete columns, industrial steel beams, and warehouse loading bay facades.
Procurement Note: Fengtaida B2B platform supports wholesale pricing and customized structural modifications for security mounting brackets. Reach out for custom OEM manufacturing info.
Suspend your dome cameras safely from high ceilings, structural beams, or outdoor overhangs. Designed for commercial warehouses, high-ceiling lobbies, and outdoor soffits, this heavy-duty pendant mount extension bracket places your camera at the perfect height for optimal coverage.
Key Engineering Highlights
- Rugged Build Quality: Formed from high-grade aluminum alloy with seamless welding, preventing structural fatigue.
- Water-Shedding Design: Internal hollow channel routes cabling directly through the pipe, protecting connectors from moisture and dust ingress (IP66 layout).
- Stable Extension: 200 mm extension pipe with standard G1.5 threads ensures a rigid connection, eliminating low-frequency vibrations from HVAC systems.
- Corrosion Shield: Electrostatic spray finish resists acid rain, salt spray, and extreme heat.
Engineering Specifications
| Parameter | Value |
|---|---|
| Material | Aluminum Alloy |
| Thread Specification | G1.5 (Inches) / Standard PTZ Thread |
| Load Capacity | 10 kg / 22 lbs |
| Cable Management | Internal routing through extension pipe |
| Length | 200 mm standard (custom lengths available) |
Typical Field Scenarios
Widely deployed in commercial retail supermarkets, railway station waiting halls, underground parking garages, logistics distribution hubs, and under-eave outdoor locations. Protects critical cabling from vandalism.
Procurement Note: Custom length pipes (30cm, 50cm, 100cm) and threaded adapters can be manufactured to your exact engineering drawings. Inquire with Fengtaida OEM factory team today.
Heavy-duty steel pole mount adapter designed for secure outdoor installation on round pillars, utility poles, and streetlights. Pairing this adapter with stainless steel straps lets you mount heavy dome cameras or floodlights without drilling into structural poles.
Key Engineering Highlights
- Marine-Grade Options: Crafted from structural steel with hot-dip galvanizing, or premium SUS304 stainless steel, offering maximum resistance against marine air and industrial chemical pollution.
- Flexible Diameter: Includes adjustable SUS304 steel straps, fitting utility poles from 67 mm up to 127 mm (custom larger clamps available on demand).
- No-Slip Grip: Designed with a precision flat-back mounting base and dual anti-skid tabs, preventing sliding even under high-vibration motorway environments.
- Double-Hole Matrix: Multi-pattern mounting surface accommodates medium and large wall mounts, waterproof boxes, and small solar chargers.
Engineering Specifications
| Parameter | Value |
|---|---|
| Material Options | Galvanized Steel / SUS304 Stainless Steel |
| Supported Pole Diameter | 67 mm to 127 mm (Adjustable) |
| Load Bearing | 20 kg / 44 lbs max |
| Steel Strap Width | 12.7 mm standard |
| Overall Plate Size | 117 mm x 113 mm x 45 mm |
Typical Field Scenarios
Excellent for public safety cameras, traffic surveillance installations, solar power station perimeters, port facility monitoring, and parking lot street lamp poles. No welding or drilling required.
Procurement Note: Bulk orders include pre-assembled high-torque clamps. Custom sizes and structural engineering stamping support available for B2B distributors and system integrators. Send us your specifications.
Secure your PTZ and dome cameras around sharp structural corners with industrial-grade stability. This heavy-duty corner mount adapter is designed to eliminate camera shake in high-wind outdoor environments, ensuring uncompromised surveillance footage.
Key Engineering Highlights
- Premium Material: Die-cast aluminum alloy (ADC12) structure, preventing rust and mechanical failure under extreme weather conditions.
- High Load Capacity: Rated for loads up to 15 kg (33 lbs), making it perfectly suitable for large-caliber speed domes and dual-lens positioning cameras.
- Universal Hole Pattern: Pre-drilled mounting holes match industry-standard wall mount brackets, saving installation time on-site.
- Industrial Finish: Double-layer powder coat in signal white (RAL9003) for excellent UV resistance and aesthetics.
Engineering Specifications
| Parameter | Value |
|---|---|
| Material | Heavy-duty Die-cast Aluminum (ADC12) |
| Load Bearing | 15 kg / 33 lbs max |
| Dimensions | 126 mm x 105 mm x 250 mm |
| Weight | 1.45 kg (3.2 lbs) |
| Color | White (Powder Coating, RAL9003) |
Typical Field Scenarios
Perfect for mounting surveillance cameras on outdoor building corners, highway toll gates, perimeters of warehouse docks, and industrial parks. It provides a full 270-degree viewing angle when paired with high-performance PTZ cameras.
Procurement Note: Fengtaida is a professional OEM/ODM manufacturer. We support bulk discounts, custom color matching (black/grey), and customized mounting plate hole designs for large engineering projects. Contact our engineering sales team for a custom quote.
Protect your power adapters, PoE injectors, and cable connections from rain, moisture, and vandalism. This outdoor waterproof power junction box is the ultimate safeguard for commercial and residential camera wiring systems.
Key Engineering Highlights
- True IP66 Protection: High-performance silicone sealing gasket provides complete protection against water sprays and fine dust, keeping critical electronics bone-dry.
- Robust Construction: Die-cast aluminum alloy body resists impacts (IK10 rated) and physical vandalism, outperforming cheap PVC boxes in commercial zones.
- Smart Cable Management: Equipped with threaded PG11 liquid-tight cable glands and internal cable strain reliefs, ensuring clean wiring and watertight seals.
- Spacious Chamber: Ample internal space easily fits AC-DC power modules, RJ45 waterproof couplers, and surge protectors.
Engineering Specifications
| Parameter | Value |
|---|---|
| Waterproof Rating | IP66 / NEMA 4X equivalent |
| Impact Rating | IK10 (Vandal-Proof) |
| Material | Die-cast Aluminum Alloy |
| Gland Size | 2 x PG11 entry ports |
| Internal Dimensions | 134 mm x 122 mm x 50 mm |
Typical Field Scenarios
Installed at outdoor camera nodes, building facades, seaport shipping berths, security check-points, and agricultural farms where weather extremes require physical protection for cable terminations.
Procurement Note: We provide custom gland drilling, pre-terminated terminal blocks, and custom branding (OEM logo printing) for industrial orders. Request a bulk-pricing sheet today.
